Semi-automatic filter bag body welder welding machine line

Item No.: SIIC-M006
SIIC-M006 semi-automatic filter bag welder welding machine line is special production line for making filter bag body, normal temperature needle punched felt filter bag without ptfe lamination is available.
INQUIRY
Description
Semi-automatic filter bag body welder welding machine line
Model No: SIIC-M006

SIIC-M006 semi-automatic filter bag welder welding machine line is special production line for making filter bag body, normal temperature needle punched felt filter bag without ptfe lamination is available.

Specification data:
Main parts: feeding part, center aligning frame, tube supporter and welding machine head
Welding speed: 10-15m/min
Melting Temperaturemax tem 640℃(be adjustable
Melting width15mmbe adjustable
Welding cloth thickness: 0.5-2.5mm
Power2.75kw220V50Hz)(average1.5kw
Size: Welding line standard working space: 280*150*150cm

Features:
-Special for welding filter bags, filter socks and filter sleeve body.
-available filter bag cloth: liquid filtration filter felt of PP, PE felt, dust collector filtration needle punched felt of PP, PE, PPS, Acrylic
-Capacity: 7-12 meter per minute.
-Weld the filter cloth automatically.
-With the adjustable tube holder, it can weld different diameter tube size with one tube holder.
-The puller feed the material actively to avoid the cloth dislocation and make the scrap in uniform.
-Temperature and hot melting speed, press of puller can adjust separately.
-The deviation of the hot melting temperature is within ±1 to keep the better melting quality
-With imported electric furnace heating wire to keep the precise of temperature
-With advantage temperature control way to avoid the frequently connect and power off of electricity

Applications:
Widely used in filter bag factory and manufacturer, when you order qty is not large or make sample order of seamless filter bag, this semi-automatic filter bag welding machine is your best choice, welded filter bag is used to replace seamless filter bags.
Semi-automatic filter bag welder welding machine line is specially for welding dust collector filter bags or liquid filter bag, normal temperature needle punched felt filter bag without ptfe lamination is available.
